D201-S XPT Q6055 Explosion-Protected PTZ Network Camera
In Stock
|
Call For Price
(0808 189 1246)
Specifications
Performance
Preset points
Yes
Infrared (IR) cut-off filter
Yes
Fog proof
Yes
Type
IP security camera
Connectivity technology
Wired
PTZ control (Pan/Tilt/Zoom)
Yes
Placement supported
Indoor & outdoor
Auto-tracking
Yes
Wide Dynamic Range (WDR)
Yes
Plug and Play
Yes
Design
Fog proof
Yes
Form factor
Dome
Product colour
Stainless steel
Mounting type
Ceiling
Protection features
Corrosion resistantExplosion proof
International Protection (IP) code
IP66
Housing material
Stainless steel
Camera
Minimum illumination
0.04 lx
Viewing angle horizontal
62.8°
Viewing angle vertical
36.8°
Tilt angle range
0 - 220°
Tilt speed
450 °/sec
Pan range
0 - 360°
Pan speed
450 °/sec
Camera shutter speed
1/33000 - 1/4 s
Camera pan control
Yes
Camera tilt control
Yes
Progressive scan
Yes
Image sensor
Sensor type
CMOS
Progressive scan
Yes
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Number of sensors
1
Lens system
Number of lenses
1
Maximum aperture number
4.41
Auto focus
Yes
Minimum aperture number
1.6
Zoom capability
Yes
Optical zoom
32x
Digital zoom
12x
Focal length range (f-f)
4.44 - 142.6 mm
Video
Image quality adjustment
Brightness Color depth Contrast Sharpness
Text caption overlay
Yes
Privacy masking
Yes
Highlight Compensation (HLC)
Yes
Bit rate control
Variable Bit Rate (VBR)
Back Light Compensation (BLC)
Yes
Video compression formats
AVCH.264M-JPEGMPEG4
Maximum resolution
1920 x 1080 pixels
Supported graphics resolutions
320 x 1801280 x 720 (HD 720)1920 x 1080 (HD 1080)
Supported video modes
720p1080p
Frame rate
60 fps
Video streaming
Yes
Network
Networking standards
IEEE 802.1x
Quality of Service (QoS) support
Yes
Streaming method
Multicast
Ethernet LAN
Yes
Storage
ROM capacity
512 MB
Card reader integrated
Yes
Compatible memory cards
SDSDHCSDXC
Flash memory
128 MB
Ports & interfaces
Terminal block port
Yes
Connectivity technology
Wired
Security
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Password protection
Yes
Power
Power source type
DCPoE
Power consumption (max)
60 W
Power consumption (typical)
16 W
Operational conditions
Operating temperature (T-T)
-50 - 60 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Weight & dimensions
Width
200 mm
Depth
200 mm
Height
400 mm
Weight
28 kg
Packaging content
Number of cameras
1
Memory card included
Yes
Included memory card size
64 GB
Manual
Yes
Other features
Video compression formats
AVCH.264M-JPEGMPEG4
D201-S XPT Q6055 Explosion-Protected PTZ Network Camera
| Length | 20.00 cm |
| Width | 20.00 cm |
| Height | 40.00 cm |
| Weight | 28.000000 kgs |
