Moxa EDS-305-S-SC-80 network switch Unmanaged
In Stock
|
$38.96
$46.75 (Inc. VAT)
Ports & interfaces
Copper ethernet cabling technology
100BASE-TX, 10BASE-T
Basic switching RJ-45 Ethernet ports quantity
5
Fiber ports quantity
1
Fiber optic connector
SC
Power connector
DC-in jack
Optical fiber
Fiber optic connector
SC
Wavelength
1550 nm
Transmission distance (max)
80 km
RX sensitivity
-34 dB
Link budget
29 dB
Fiber type
Single-mode
Fiber ethernet cabling technology
100BASE-FX
Performance
Stackable
Yes
Mean time between failures (MTBF)
422000 h
Power
Power connector
DC-in jack
Input voltage
12 - 48 V
Input current
0.13 A
Power source
AC/DC
Technical details
Stackable
Yes
Mean time between failures (MTBF)
422000 h
Management features
Switch type
Unmanaged
Network
Copper ethernet cabling technology
100BASE-TX, 10BASE-T
Networking standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Full duplex
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
10G support
No
Data transmission
MAC address table
1000 entries
Supported data transfer rates
10/100 Mbps
Switching capacity
0.1 Gbit/s
Store-and-forward
Yes
Maximum data transfer rate
0.1 Gbit/s
Certificates
Certification
UL508, UL60950-1, CSA C22.2 No. 60950-1, EN60950-1
UL/cUL
FCC
EMS: EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS)
DNV, GL
IEC 60068-2-27
IEC 60068-2-32
IEC 60068-2-6
Design
Stackable
Yes
Certification
UL508, UL60950-1, CSA C22.2 No. 60950-1, EN60950-1
UL/cUL
FCC
EMS: EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS)
DNV, GL
IEC 60068-2-27
IEC 60068-2-32
IEC 60068-2-6
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Storage temperature (T-T)
-40 - 85 °C
Operating temperature (T-T)
0 - 60 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Weight
630 g
Other features
Dimensions (WxDxH)
53.6 x 105 x 135 mm
Networking features
Fast Ethernet
Input voltage
12 - 48 V
Moxa EDS-305-S-SC-80 network switch Unmanaged
