Uninterruptible power supplies UPS

Output power

2200 W

Input operation voltage (min)

160 V

Input operation voltage (max)

294 V

Output power capacity

2.2 kVA

UPS topology

Line-Interactive

Waveform

Pure sine

LED indicators

Yes

Power protection features

Overdischarge

Noise level

40 dB

UPS topology

Line-Interactive

Waveform

Pure sine

Output power

2200 W

Input operation voltage (min)

160 V

Input operation voltage (max)

294 V

Power protection features

Overdischarge

Noise level

40 dB

Output power capacity

2.2 kVA

Input frequency

47/70 Hz

USB port

Yes

Serial interface

Yes

Serial interface type

RS-232

AC outlet types

C13 coupler, C19 coupler

Power plug

C20 coupler

Serial ports quantity

1

Automatic battery test

Yes

Rack capacity

2U

Form factor

Rackmount/Tower

LED indicators

Yes

Product colour

Black

Safety

IEC/EN 62040-1, UL1778, CSA22.2

Certification

IEC/EN 62040-2, FCC B, CISPR22 B CB (TUV) / cTUVus / EAC / UKCA / Ukr / Cm

Display type

LCD

Operating temperature (T-T)

0 - 40 °C

Sustainability compliance

Yes

Harmonized System (HS) code

85078000

Compliance certificates

CE

Weight

28.2 kg

Width

438 mm

Height

85.5 mm

Depth

603 mm

Management card included

Yes

Harmonized System (HS) code

85078000

Safety

IEC/EN 62040-1, UL1778, CSA22.2

Certification

IEC/EN 62040-2, FCC B, CISPR22 B CB (TUV) / cTUVus / EAC / UKCA / Ukr / Cm

Output connections

8 x IEC C13 (10A) 2 x IEC C19 (16A)

Nominal output voltage

230 V
