Allied Telesis AT-IMC200TP/SC-980 network media converter 100 Mbit/s 1310 nm Grey
In Stock
|
Call For Price
(0808 189 1246)
Network
Fiber optic connector
SC
Jumbo frames support
Yes
Store-and-forward
Yes
Packet forwarding rate (100 Mbps)
148800 pps
Packet forwarding rate (10 Mbps)
14880 pps
Packet forwarding rate (1 Gbps)
1488000 pps
Auto-negotiation
Yes
Jumbo frames
10000
VLAN support
Yes
Ethernet LAN data rates
10-100 Mbit/s
Ethernet interface type
Fast Ethernet
Converter output interface
100Base-FX
Auto MDI/MDI-X
Yes
Maximum data transfer rate
100 Mbit/s
Technical details
International Protection (IP) code
IP30
Wavelength
1310 nm
Maximum transfer distance
2000 m
Tx power (min)
-19 dBmW
Tx power (max)
-14 dBmW
Rx power (min)
-32 dBmW
Rx power (max)
-3 dBmW
Internal
No
Sustainability certificates
RoHS
Performance
Jumbo frames support
Yes
Store-and-forward
Yes
Auto-negotiation
Yes
Wavelength
1310 nm
Maximum transfer distance
2000 m
Tx power (min)
-19 dBmW
Tx power (max)
-14 dBmW
Rx power (min)
-32 dBmW
Rx power (max)
-3 dBmW
Ports & interfaces
Power over Ethernet plus (PoE+) ports quantity
1
Connectivity technology
Wired
Fiber ports quantity
1
Fiber optic connector
SC
Indication
LED indicators
Yes
Design
DIN rail mounting
Yes
International Protection (IP) code
IP30
LED indicators
Yes
Product colour
Grey
Internal
No
Power
Power over Ethernet (PoE)
Yes
Colour
Product colour
Grey
Weight & dimensions
Width
111 mm
Depth
96 mm
Weight
748 g
Height
35 mm
Allied Telesis AT-IMC200TP/SC-980 network media converter 100 Mbit/s 1310 nm Grey
