Intel Core CM8071504654209
In Stock
|
Call For Price
(0808 189 1246)
Processor
Processor generation
12th gen Intel® Core⢠i3
Processor manufacturer
Intel
Processor codename
Alder Lake
Memory bandwidth supported by processor (max)
76.8 GB/s
Processor cache
12 MB
Processor ARK ID
132225
Processor model
i3-12100E
Processor threads
8
Processor operating modes
64-bit
Processor boost frequency
4.2 GHz
Bus type
DMI4
Processor family
Intel® Core⢠i3
Processor cores
4
Box
No
Processor socket
LGA 1700
Processor cache type
Smart Cache
Performance cores
4
Performance-core boost frequency
4.2 GHz
Performance-core base frequency
3.2 GHz
Processor base power
60 W
Maximum number of DMI lanes
8
Memory
Maximum internal memory supported by processor
128 GB
Memory types supported by processor
DDR4-SDRAM- DDR5-SDRAM
Memory bandwidth supported by processor (max)
76.8 GB/s
Memory channels
Dual-channel
Memory bandwidth (max)
76.8 GB/s
ECC
Yes
Graphics
Discrete graphics card
No
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b- DisplayPort 1.4a- HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
Number of execution units
24
On-board graphics card ID
0x4692
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
Number of displays supported (on-board graphics)
4
On-board graphics card maximum resolution (HDMI)
4096 x 2160 pixels
On-board graphics card DirectX version
12.0
On-board graphics card OpenGL version
4.5
On-board graphics card model
Intel UHD Graphics 730
On-board graphics card
Yes
On-board graphics card dynamic frequency (max)
1400 MHz
On-board graphics card base frequency
300 MHz
Discrete graphics card model
Not available
Multi-Format Codec Engines
1
Technical details
Intel® Secure Key
Yes
Thermal Monitoring Technologies
Yes
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Idle States
Yes
Execute Disable Bit
Yes
Enhanced Intel SpeedStep Technology
Yes
PCI Express slots version
5.0- 4.0
PCI Express configurations
1x16+1x4- 2x8+1x4
Supported instruction sets
SSE4.1- SSE4.2- AVX 2.0
Scalability
1S
L2 cache
5120 KB
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
Yes
CPU configuration (max)
1
Graphics output
eDP 1.4b- DP 1.4a- HDMI 2.1
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Status
Launched
Market segment
Embedded
Launch date
Q1'22
Intel Virtualization Technology (VT-x)
Yes
Processor cache type
Smart Cache
OpenCL version
2.1
Features
On-board graphics card ID
0x4692
Maximum number of PCI Express lanes
20
Processor package size
45 x 37.5 mm
Processor ARK ID
132225
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
PCI Express slots version
5.0- 4.0
PCI Express configurations
1x16+1x4- 2x8+1x4
Supported instruction sets
SSE4.1- SSE4.2- AVX 2.0
Scalability
1S
Embedded options available
Yes
CPU configuration (max)
1
Market segment
Embedded
Harmonized System (HS) code
85423119
Export Control Classification Number (ECCN)
5A992CN3
Commodity Classification Automated Tracking System (CCATS)
G167599
Use conditions
Embedded Broad Market Commercial Temp
Direct Media Interface (DMI) Revision
4.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Intel Turbo Boost Max Technology 3.0
No
Intel® Speed Shift Technology
Yes
Intel® Optane⢠Memory Ready
No
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel® Boot Guard
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
No
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Time Coordinated Computing (Intel® TCC)
Yes
Operational conditions
Tjunction
100 °C
Logistics data
Harmonized System (HS) code
85423119
Weight & dimensions
Processor package size
45 x 37.5 mm
Other features
Maximum internal memory
128 GB
L2 cache
5120 KB
CPU configuration (max)
1
Graphics output
eDP 1.4b- DP 1.4a- HDMI 2.1
Intel Core CM8071504654209
