Intel Core i7-14700 processor 33 MB Smart Cache
In Stock
|
£336.36
£403.63 (Inc. VAT)
get it next day (UK Mainland Orders)
Intel Core i7-14700 processor 33 MB Smart Cache
Write Your Own Review
Processor
Processor generation
Intel® Core⢠i7 (14th gen)
Processor manufacturer
Intel
Processor codename
Raptor Lake
Memory bandwidth supported by processor (max)
89.6 GB/s
Processor cache
33 MB
Processor ARK ID
236781
Processor model
i7-14700
Processor threads
28
Processor operating modes
64-bit
Processor boost frequency
5.4 GHz
Stepping
B0
Processor family
Intel® Core⢠i7
Processor cores
20
Box
No
Processor socket
LGA 1700
Processor cache type
Smart Cache
Performance cores
8
Efficient cores
12
Performance-core boost frequency
5.3 GHz
Performance-core base frequency
2.1 GHz
Efficient-core boost frequency
4.2 GHz
Efficient-core base frequency
1.5 GHz
Processor base power
65 W
Maximum turbo power
219 W
Maximum number of DMI lanes
8
Memory
Maximum internal memory supported by processor
192 GB
Memory types supported by processor
DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth supported by processor (max)
89.6 GB/s
Memory channels
Dual-channel
Memory bandwidth (max)
89.6 GB/s
ECC
Yes
Graphics
Discrete graphics card
No
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
Number of execution units
32
On-board graphics card ID
0xA780
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
Number of displays supported (on-board graphics)
4
On-board graphics card maximum resolution (HDMI)
4096 x 2160 pixels
On-board graphics card DirectX version
12
On-board graphics card OpenGL version
4.5
On-board graphics card model
Intel UHD Graphics 770
On-board graphics card
Yes
On-board graphics card dynamic frequency (max)
1600 MHz
On-board graphics card base frequency
300 MHz
Discrete graphics card model
Not available
Multi-Format Codec Engines
2
Technical details
Intel® Secure Key
Yes
Thermal Monitoring Technologies
Yes
Intel® Turbo Boost Technology
2
Intel® Quick Sync Video Technology
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Idle States
Yes
Execute Disable Bit
Yes
Enhanced Intel SpeedStep Technology
Yes
PCI Express slots version
4.0, 5.0
PCI Express configurations
1x16+1x4, 2x8+1x4
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
L2 cache
28672 KB
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
Yes
CPU configuration (max)
1
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Status
Launched
Market segment
Desktop
Launch date
Q1'24
Intel Virtualization Technology (VT-x)
Yes
Processor cache type
Smart Cache
OpenCL version
3
Features
On-board graphics card ID
0xA780
Maximum number of PCI Express lanes
20
Processor package size
45 x 37.5 mm
Processor ARK ID
236781
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
PCI Express slots version
4.0, 5.0
PCI Express configurations
1x16+1x4, 2x8+1x4
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
Embedded options available
Yes
CPU configuration (max)
1
Market segment
Desktop
Harmonized System (HS) code
8542310001
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Use conditions
Workstation, PC/Client/Tablet
Direct Media Interface (DMI) Revision
4
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel 64
Yes
Intel Turbo Boost Max Technology 3.0
Yes
Intel® Speed Shift Technology
Yes
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel® Turbo Boost Technology
2
Intel® Quick Sync Video Technology
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel® Boot Guard
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Turbo Boost Max Technology 3.0 frequency
5.4 GHz
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® Standard Manageability (ISM)
Yes
Operational conditions
Tjunction
100 °C
Logistics data
Harmonized System (HS) code
8542310001
Weight & dimensions
Processor package size
45 x 37.5 mm
Other features
Maximum internal memory
192 GB
L2 cache
28672 KB
CPU configuration (max)
1
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
| Weight | 0.06 kgs |
