TP-Link Omada DR3220v-4G wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Ethernet WAN

Yes

Ethernet LAN interface type

Gigabit Ethernet

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Cabling technology

10/100/1000Base-T(X)

DSL WAN

Yes

ADSL

Yes

ADSL2

Yes

ADSL2+

Yes

VDSL2

Yes

SIM card slot

No

3G/4G USB modem compatibility

Yes

Network address translation (NAT)

Yes

Guest access

Yes

Ethernet LAN interface type

Gigabit Ethernet

Ethernet LAN

Yes

VPN support

IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

Ethernet LAN data rates

10,100,1000 Mbit/s

Cabling technology

10/100/1000Base-T(X)

Port triggering

Yes

Built-in FTP server

Yes

Static route

Yes

Policy-based routing

Yes

Load balancing system

Yes

Dynamic DNS (DDNS)

Yes

DMZ support

Yes

Voice codecs

G.711a, G.711ulaw, G.722, G.726, G.729ab

Universal Plug and Play (UPnP)

Yes

DHCP server

Yes

DHCP client

Yes

Universal Plug and Play (UPnP)

Yes

Web-based management

Yes

Reset button

Yes

Quality of Service (QoS) support

Yes

MU-MIMO technology

Yes

VPN support

IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN

URL filtering

Yes

System event log

Yes

Security algorithms

WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal

Network address translation (NAT)

Yes

Guest access

Yes

DMZ support

Yes

Access Control List (ACL)

Yes

Voice codecs

G.711a, G.711ulaw, G.722, G.726, G.729ab

Package type

Box

Number of products included

1 pc(s)

Cables included

LAN (RJ-45), Phone

AC adapter included

Yes

Antenna included

Yes

Ethernet WAN

Yes

DSL WAN

Yes

SIM card slot

No

3G/4G USB modem compatibility

Yes

WAN connection type

RJ-45

WLAN data transfer rate (max)

2402 Mbit/s

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

WLAN data transfer rate (first band)

574 Mbit/s

WLAN data transfer rate (second band)

2402 Mbit/s

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

USB port

Yes

RJ-11 ports quantity

3

Ethernet LAN (RJ-45) ports

4

DC-in jack

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Product type

Tabletop router

Wall mountable

Yes

LED indicators

DSL, LAN, USB, WLAN

Product colour

Black

Indication light

Yes

Antenna design

External

Detachable antenna(s)

Yes

Antennas quantity

3

Antenna gain level (max)

4.5 dBi

Power source type

AC

Output voltage

12 V

Output current

3.3 A

Storage temperature (T-T)

-40 - 70 °C

Storage relative humidity (H-H)

5 - 90%

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Width

226 mm

Height

35 mm

Depth

131 mm

Package type

Box

Cables included

LAN (RJ-45), Phone

AC adapter included

Yes

Number of products included

1 pc(s)

Antenna included

Yes
