Synology DS925+/16TB-HAT3300

Total installed storage capacity

16 TB

Storage drives installed

Yes

Installed storage drive type

HDD

Number of storage drives installed

9

Supported storage drive types

HDD & SSD

Number of storage drives supported

9

Maximum supported storage capacity

180 TB

Storage drive interface

M.2, Serial ATA

Hot-swap drive bays

Yes

RAID support

Yes

Supported file systems

BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4

RAID levels

0, 1, 5, 6, 10, JBOD

Supported storage drive interfaces

M.2, Serial ATA

Storage drive sizes supported

2.5,3.5,M.2

Number of M.2 (M & B) slots

2

Processor generation

AMD Ryzen Embedded V1000 Series

Processor manufacturer

AMD

Processor threads

8

Processor frequency

2.2 GHz

Processor family

Ryzen Embedded

Processor model

V1500B

Processor cores

4

Internal memory type

DDR4

Internal memory

4 GB

Maximum RAM supported

32 GB

Memory slots

2

Memory form factor

SO-DIMM

ECC

Yes

Ethernet LAN

Yes

Ethernet LAN data rates

2500 Mbit/s

Wake-on-LAN ready

Yes

Supported network protocols

SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

USB port

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Ethernet LAN (RJ-45) ports

2

RAID support

Yes

Supported file systems

BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4

RAID levels

0, 1, 5, 6, 10, JBOD

Fan diameter 2

9.2 cm

Cooling type

Active

Fan diameter

9.2 cm

Drive bay locking

Yes

Product colour

Black

Number of fans

2 fan(s)

LED indicators

Yes

Type

NAS

Device class

Home & Home Office

Backup function

Yes

Backup features

Cloud, iSCSI LUN

Product colour

Black

Number of users

512 user(s)

Noise level

20.5 dB

Multilingual support

Yes

LED indicators

Yes

Number of fans

2 fan(s)

Compliance certificates

RoHS

System log

No

Browser supported

Chrome,Firefox,Edge,Safari

Type

NAS

Device class

Home & Home Office

Backup function

Yes

Backup features

Cloud, iSCSI LUN

On/off switch

Yes

Web-based management

Yes

Number of users

512 user(s)

Noise level

20.5 dB

Multilingual support

Yes

Access Control List (ACL)

Yes

Snapshot

Yes

Cooling type

Active

Fan diameter

9.2 cm

Number of fans

2 fan(s)

Drive bay locking

Yes

Access Control List (ACL)

Yes

On/off switch

Yes

Web-based management

Yes

Power consumption (HDD standby)

12.33 W

Power supply location

External

Power supply unit (PSU) capacity

100 W

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power consumption (typical)

37.91 W

External power adapter

Yes

Width

199 mm

Depth

223 mm

Height

166 mm

Weight

2.26 kg

External power adapter

Yes

Cables included

AC, LAN (RJ-45)

Power cables quantity

1

Storage temperature (T-T)

Storage relative humidity (H-H)

5 - 95%

Operating temperature (T-T)

Operating relative humidity (H-H)

5 - 95%

Certification

FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS

Cables included

AC, LAN (RJ-45)

Certification

FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS

Compliance certificates

RoHS
