Zyxel ES1100-8P-GB0102F Unmanaged Fast Ethernet Power over Ethernet (PoE)
In Stock
|
$50.00
$60.00 (Inc. VAT)
Performance
Packet buffer memory
0.096 MB
Mean time between failures (MTBF)
164603 h
Technical details
Product colour
Black
Mean time between failures (MTBF)
164603 h
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity
8
Network
Networking standards
IEEE 802.1p-IEEE 802.3-IEEE 802.3af-IEEE 802.3az-IEEE 802.3u-IEEE 802.3x
Full duplex
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
10G support
No
Data transmission
Packet buffer memory
0.096 MB
MAC address table
1024 entries
Switching capacity
1.6 Gbit/s
Store-and-forward
Yes
Jumbo frames support
Yes
Certificates
Safety
EN 60950-1- IEC 60950-1
Certification
CE EMC FCC Part 15 (Class A) RoHS
Memory
Packet buffer memory
0.096 MB
Design
Safety
EN 60950-1- IEC 60950-1
Product colour
Black
LED indicators
Yes
Certification
CE EMC FCC Part 15 (Class A) RoHS
Indication
LED indicators
Yes
Power
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
64 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity
4
Power over Ethernet (PoE)
Yes
Operational conditions
Storage temperature (T-T)
-40 - 70 °C
Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
10 - 95%
Heat dissipation
255.41 BTU/h
Weight & dimensions
Width
262 mm
Depth
184 mm
Height
41 mm
Weight
1.4 kg
Packaging data
Package width
318 mm
Package depth
275 mm
Package height
73 mm
Package weight
2.2 kg
Zyxel ES1100-8P-GB0102F Unmanaged Fast Ethernet Power over Ethernet (PoE)
| Length | 18.40 cm |
| Width | 26.20 cm |
| Height | 4.10 cm |
| Weight | 1.400000 kgs |
