Ruckus ICX 7550-24ZP-E2 - Switch - L3 - managed - 12 x 10/100/1000/2.5G (PoE++) + 12 x 100/1000/2.5/5/10G (PoE++) + 2 x 40/100 Gigabit QSFP+ - front to back airflow - rack-mountable - PoE+ (2000 W)
0 Reviews
| Add your review
In Stock
|
Call For Price
(0808 189 1246)
| SPECIFICATIONS | |
|---|---|
| Product Description | Ruckus ICX 7550-24ZP-E2 - switch - 24 ports - managed - rack-mountable |
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Subtype | 10 Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 2000 W |
| Jumbo Frame Support | 12288 bytes |
| Power | AC 120/230 V (50/60 Hz) |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 17.3 in x 16 in x 1.7 in |
| Weight | 15.39 lbs |
| General | |
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 2000 W |
| Jumbo Frame Support | 12288 bytes |
| Max Units In A Stack | 12 |
| Routing Protocol | RIP-1 RIP-2 static IPv4 routing static IPv6 routing ECMP |
| Remote Management Protocol | SNMP 1 SNMP 3 SNMP 2c HTTP HTTPS TFTP SSH-2 CLI |
| Encryption Algorithm | AES |
| Authentication Method | RADIUS TACACS TACACS+ Secure Shell v.2 (SSH2) |
| RAM | 4 GB |
| Flash Memory | 4 GB |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 (installed) / 2 (max) |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Power Provided | 1200 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 1152 Watt |
| Miscellaneous | |
| MTBF | 287.828 hours |
| Dimensions & Weight | |
| Width | 17.3 in |
| Depth | 16 in |
| Height | 1.7 in |
| Weight | 15.39 lbs |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% (non-condensing) |
Ruckus ICX 7550-24ZP-E2 - Switch - L3 - managed - 12 x 10/100/1000/2.5G (PoE++) + 12 x 100/1000/2.5/5/10G (PoE++) + 2 x 40/100 Gigabit QSFP+ - front to back airflow - rack-mountable - PoE+ (2000 W)
| Length | 16 cm |
| Width | 17.3 cm |
| Height | 1.7 cm |
| Weight | 1.000000 kgs |
