TP-Link InSight S245ZI Dome IP security camera Outdoor 2688 x 1520 pixels Ceiling

Infrared (IR) cut-off filter

Yes

Remote viewing

Yes

Type

IP security camera

Connectivity technology

Wired

Placement supported

Outdoor

Wide Dynamic Range (WDR)

Yes

Day/night mode

Yes

Maximum operating distance

200 m

Dynamic range

120 dB

Weatherproof

Yes

IK code

IK10

Form factor

Dome

Product colour

White

Mounting type

Ceiling

Protection features

Waterproof

International Protection (IP) code

IP67

Housing material

Metal

Minimum illumination

0 lx

Tilt angle range

0 - 75°

Camera shutter speed

1/3 to 1/10000

Camera pan control

Yes

Camera tilt control

Yes

Lens viewing angle, horizontal

29.6 - 102°

Lens viewing angle, vertical

16.8 - 53.8°

Lens viewing angle, diagonal

34.1 - 122.8°

Progressive scan

Yes

Sensor type

CMOS

Progressive scan

Yes

Optical sensor size

25.4 / 2.9 mm (1 / 2.9")

Maximum aperture number

1.6

Auto focus

Yes

Detect distance

200 m

Observe distance

84 m

Recognize distance

40 m

Identify distance

21 m

Focus

Motorized

Optical zoom

5x

Night vision

Yes

LED type

IR/White

Image quality adjustment

Brightness, Contrast, Mirror, Saturation, Sharpness

Highlight Compensation (HLC)

Yes

Digital Wide Dynamic Range (DWDR)

Yes

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Bit rate

Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264

Back Light Compensation (BLC)

Yes

Video compression formats

H.264, H.264+, H.265, H.265+

Maximum resolution

2688 x 1520 pixels

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520

Total megapixels

4 MP

Video recording

Yes

Audio input channels

1.0 channels

Audio output channels

1.0 channels

Built-in speaker(s)

Yes

Sample rate

8 kHz

Built-in microphone

Yes

Audio system

2-way

Audio formats supported

G.711 A-law

Bit rate range

0 - 64 Kbit/s

Number of microphones

1

Bluetooth

No

Networking standards

IEEE 802.3af, IEEE 802.3at

Ethernet LAN

Yes

Wi-Fi

No

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

Live view

Yes

Maximum memory card size

512 GB

Compatible memory cards

MicroSD (TransFlash)

Ethernet LAN (RJ-45) ports

1

DC-in jack

Yes

Connectivity technology

Wired

Alert notification type

Push notification

Intelligent Video Surveillance (IVS) system features

Abnormal sound detection, Crossing line, Human detection, Intrusion, Line crossing detection, Moving object, Region entrance detection, Region exiting detection, Scene change, Vehicle detection

Motion sensor

Yes

Detection distance

200 m

Video motion detection

Yes

IP address filtering

Yes

HTTPS encryption

Yes

Password protection

Yes

Mirror

Yes

Built-in siren

Yes

Human and vehicle targets classification

Yes

Digest authentication

Yes

Web browser

Yes

Web-based management

Yes

Reset button

Yes

Cloud-managed

Yes

Power source type

DC, PoE

Power consumption (max)

10.8 W

Power consumption (Power over Ethernet (PoE))

12 W

DC-in jack

Yes

DC output voltage

12

Operating temperature (T-T)

-30 - 60 °C

Storage temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Package type

Box

Width

129.9 mm

Depth

129.9 mm

Height

102.5 mm

Weight

775 g

Package type

Box

Number of cameras

1

Package type

Box

Manual

Yes

Focus

Motorized

Video compression formats

H.264, H.264+, H.265, H.265+
