TP-Link InSight S345S Bullet IP security camera Outdoor 2688 x 1520 pixels Ceiling/Wall/Pole

Infrared (IR) cut-off filter

Yes

Type

IP security camera

Connectivity technology

Wired

Placement supported

Outdoor

Wide Dynamic Range (WDR)

Yes

Alarm input/output

Yes

Dynamic range

120 dB

Form factor

Bullet

Product colour

White

Mounting type

Ceiling/Wall/Pole

International Protection (IP) code

IP67

Housing material

Metal

Minimum illumination

0.0005 lx

Tilt angle range

0 - 75°

Pan range

0 - 360°

Angle of rotation

360°

Camera shutter speed

1/3 - 1/10000 s

Lens viewing angle, horizontal

95°

Lens viewing angle, vertical

51°

Lens viewing angle, diagonal

115°

Progressive scan

Yes

Sensor type

CMOS

Progressive scan

Yes

Optical sensor size

25.4 / 1.79 mm (1 / 1.79")

Number of lenses

1

Maximum aperture number

1

Detect distance

76 m

Observe distance

29 m

Recognize distance

14 m

Identify distance

7 m

Fixed focal length

4 mm

Night vision

Yes

Night vision distance

30 m

LED type

IR/White

Number of illumination LEDs

2

Infra-red wavelength

850 nm

Noise reduction

Yes

Smart IR

Yes

Region of Interest (ROI) encoding

Yes

Highlight Compensation (HLC)

Yes

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Bit rate

Main Stream: 256 Kbps - 6 Mbps; Sub-Stream: 64 Kbps - 1024 Kbps

Back Light Compensation (BLC)

Yes

Noise reduction technology

3D noise reduction

Video compression formats

H.264, H.264+, H.265, H.265+

Maximum resolution

2688 x 1520 pixels

Supported graphics resolutions

320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520

Video streaming

Yes

Total megapixels

4 MP

Built-in speaker(s)

Yes

Signal-to-Noise Ratio (SNR)

52 dB

Built-in microphone

Yes

Audio system

2-way

Bluetooth

No

Ethernet interface type

Fast Ethernet

Ethernet LAN

Yes

Wi-Fi

No

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP

Maximum memory card size

512 GB

Card reader integrated

Yes

Built-in HDD

No

Compatible memory cards

MicroSD (TransFlash)

Ethernet LAN (RJ-45) ports

1

Connectivity technology

Wired

Intelligent Video Surveillance (IVS) system features

Abandoned object, Abnormal sound detection, Human detection, Intrusion, Line crossing detection, Region entrance detection, Region exiting detection, Scene change, Vehicle detection

Video motion detection

Yes

IP address filtering

Yes

HTTPS encryption

Yes

Active tampering alarm

Yes

Password protection

Yes

Digest authentication

Yes

Alarm input channels

1

Alarm output channels

1

Web browser

Yes

Cloud-managed

Yes

Power source type

DC, PoE

DC output voltage

12

Operating temperature (T-T)

-30 - 60 °C

Storage temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Length

191 mm

Diameter

6.6 cm

Weight

600 g

Compliance certificates

BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), KC, VCCI

Number of cameras

1

Mounting kit

Yes

Manual

Yes

Compliance certificates

BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), KC, VCCI

Video compression formats

H.264, H.264+, H.265, H.265+
