TP-Link InSight S485PI Turret IP security camera Outdoor 3840 x 2160 pixels Wall

Infrared (IR) cut-off filter

Yes

Remote viewing

Yes

Type

IP security camera

Connectivity technology

Wired

Placement supported

Outdoor

Wide Dynamic Range (WDR)

Yes

Day/night mode

Yes

Maximum operating distance

44 m

Dynamic range

120 dB

Weatherproof

Yes

Form factor

Turret

Product colour

White

Mounting type

Wall

Protection features

Waterproof

International Protection (IP) code

IP67

Housing material

Metal

Minimum illumination

0 lx

Tilt angle range

0 - 90°

Camera shutter speed

1/3 to 1/10000

Lens viewing angle, horizontal

180°

Lens viewing angle, vertical

86°

Lens viewing angle, diagonal

180°

Progressive scan

Yes

Sensor type

CMOS

Progressive scan

Yes

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Sensor type (panoramic camera)

CMOS

Maximum aperture number

2

Detect distance

44 m

Observe distance

18.33 m

Recognize distance

8.8 m

Identify distance

4.4 m

Fixed focus

Yes

Fixed focal length

1.65 mm

Night vision

Yes

LED type

IR/White

Image quality adjustment

Brightness, Contrast, Mirror, Saturation, Sharpness

Highlight Compensation (HLC)

Yes

Digital Wide Dynamic Range (DWDR)

Yes

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Bit rate

Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 1024 Kbps

Back Light Compensation (BLC)

Yes

Video compression formats

H.264, H.264+, H.265, H.265+

Maximum resolution

3840 x 2160 pixels

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520, 2880 x 1620, 3840 x 2160

Total megapixels

8 MP

Video recording

Yes

Audio input channels

1.0 channels

Audio output channels

1.0 channels

Built-in speaker(s)

Yes

Sample rate

8 kHz

Built-in microphone

Yes

Audio system

2-way

Audio formats supported

G.711 A-law

Bit rate range

0 - 64 Kbit/s

Number of microphones

1

Bluetooth

No

Networking standards

IEEE 802.3at

Ethernet LAN

Yes

Wi-Fi

No

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

SIM card slot

Yes

Live view

Yes

SIM card type

MicroSIM

Maximum memory card size

512 GB

Compatible memory cards

MicroSD (TransFlash)

Ethernet LAN (RJ-45) ports

1

DC-in jack

Yes

Connectivity technology

Wired

Alert notification type

Push notification

Motion sensor

Yes

Detection distance

120 m

Video motion detection

Yes

IP address filtering

Yes

HTTPS encryption

Yes

Password protection

Yes

Mirror

Yes

Built-in siren

Yes

Human and vehicle targets classification

Yes

Digest authentication

Yes

Web browser

Yes

Web-based management

Yes

Reset button

Yes

Cloud-managed

Yes

Power source type

DC, PoE

Power consumption (max)

18 W

Power consumption (Power over Ethernet (PoE))

21 W

DC-in jack

Yes

DC output voltage

12

Operating temperature (T-T)

-30 - 60 °C

Storage temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Width

112.3 mm

Depth

112.3 mm

Height

110.2 mm

Weight

760 g

Number of cameras

1

Screws included

Yes

Mounting kit

Yes

Manual

Yes

Drilling template included

Yes

Video compression formats

H.264, H.264+, H.265, H.265+
