Performance

Country of origin

Taiwan

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1

Charger type

Indoor

Charger compatibility

Mobile computer, Mobile phone, Portable gaming console, Smartwatch, Tablet

Power source type

USB

Power protection features

Over current, Overcharge, Overheating

Compatibility

Smartphones: iPhone® 13, 13 mini, 13 pro, 13 pro max, 12 mini, 12, 12 Pro, 12 Pro Max, 11, 11 Pro, 11 Pro Max, XS Max, XR, XS, X, 8, 8 Plus Samsung® Galaxy™ Note10, Note10+, Note9, Note8, S22 Ultra, S22+, S22, S21 FE, S21 Ultra, S21, S20 FE, S20 Ultra, S20, S10, S10+, S10 Lite, S10 5G, S10e, S9+, S9, S8, S8+ Pixel™ 4, 4a, 4XL, 5, 5a, 6, 6a, 6 Pro Sony® Xperia® XZ3 LG™ G8 ThinQ™, LG™ 7 Tablets: iPad Air® 10.5'", iPad Pro® 11''/12.9" Samsung® Galaxy™ Tab S8 Ultra, S8+, S8, S7 FE, S7+, S7, S6 Lite, S6, S5e, S4 Google Pixel™ tablets Consoles: Nintendo Switch™ Nintendo Switch™ Lite Stream Deck™ *Not compatible with the Nintendo Switch™ dock. Laptops: MacBook Air® 13'', MacBook® 12'', MacBook Pro® 13'', MacBook Pro® 15", MacBook Pro® 16", M1 MacBook® computers Microsoft® Surface™ computers with power delivery Dell™ XPS™ 13, XPS™ 15, Inspiron™ 13, Inspiron™ 7000, Dell™ Vostro™ 5471 HP® Elite X2, EliteBook X360, Spectre® 13, Spectre® 15, Spectre® 360, Spectre® folio 13-ak0000tu, Chromebook™ computers Lenovo™ ThinkPad® X1, Yoga™ *Note: Compatibility is not limited to just the device listed

Fast charging

Yes

Fast charging technology

Quick Charge 4

USB Type-C ports quantity

3

USB Power Delivery

Yes

USB Power Delivery revision

3.0

USB Power Delivery up to

130 W

Number of outputs

4 outputs

Design

Product colour

Grey, White

Gallium nitride (GaN) transistors

Yes

Housing material

Plastic

Power

Maximum power

130 W

Port 1 output power

18 W

Port 2 output power

20 W

Port 3 output power

100 W

Technical details

Package type

Box

Charger type

Indoor

Charger compatibility

Mobile computer, Mobile phone, Portable gaming console, Smartwatch, Tablet

Power source type

USB

Power protection features

Over current, Overcharge, Overheating

Compatibility

Smartphones: iPhone® 13, 13 mini, 13 pro, 13 pro max, 12 mini, 12, 12 Pro, 12 Pro Max, 11, 11 Pro, 11 Pro Max, XS Max, XR, XS, X, 8, 8 Plus Samsung® Galaxy™ Note10, Note10+, Note9, Note8, S22 Ultra, S22+, S22, S21 FE, S21 Ultra, S21, S20 FE, S20 Ultra, S20, S10, S10+, S10 Lite, S10 5G, S10e, S9+, S9, S8, S8+ Pixel™ 4, 4a, 4XL, 5, 5a, 6, 6a, 6 Pro Sony® Xperia® XZ3 LG™ G8 ThinQ™, LG™ 7 Tablets: iPad Air® 10.5'", iPad Pro® 11''/12.9" Samsung® Galaxy™ Tab S8 Ultra, S8+, S8, S7 FE, S7+, S7, S6 Lite, S6, S5e, S4 Google Pixel™ tablets Consoles: Nintendo Switch™ Nintendo Switch™ Lite Stream Deck™ *Not compatible with the Nintendo Switch™ dock. Laptops: MacBook Air® 13'', MacBook® 12'', MacBook Pro® 13'', MacBook Pro® 15", MacBook Pro® 16", M1 MacBook® computers Microsoft® Surface™ computers with power delivery Dell™ XPS™ 13, XPS™ 15, Inspiron™ 13, Inspiron™ 7000, Dell™ Vostro™ 5471 HP® Elite X2, EliteBook X360, Spectre® 13, Spectre® 15, Spectre® 360, Spectre® folio 13-ak0000tu, Chromebook™ computers Lenovo™ ThinkPad® X1, Yoga™ *Note: Compatibility is not limited to just the device listed

Technical features

The first and the second USB-C® port provide up to 100W of power when used independently. The first and the second USB-C® port provide up to 65W of power when both ports are used. 【Dynamic Power Control of full load in 30mins : PD90W(PD45W+PD45W)】 The third USB-C® port provides up to 20W of power when used independently. The USB™ Type-A port provides up to 18W of power when used independently. The third USB-C® and USB™ Type-A port provide up to 20W (5V/2A+5V/2A) of power when used both ports.

Country of origin

Taiwan

Packaging content

1 - 130W GaN USB-C® 4-Port Charger 1 - Quick Installation Guide (QIG)

Weight & dimensions

Width

69 mm

Depth

32 mm

Height

87 mm

Weight

295 g

Package width

155 mm

Package depth

95 mm

Package height

40 mm

Package weight

374 g

Packaging data

Package type

Box

Package width

155 mm

Package depth

95 mm

Package height

40 mm

Package weight

374 g

Quantity per pack

1 pc(s)

Operational conditions

Operating temperature (T-T)

0 - 30 °C

Packaging content

1 - 130W GaN USB-C® 4-Port Charger 1 - Quick Installation Guide (QIG)

Package type

Box

Colour

Product colour

Grey, White

Logistics data

Products per master (outer) case

10 pc(s)

Products per shipping (inner) case

5 pc(s)

Master (outer) case width

207 mm

Master (outer) case length

224 mm

Master (outer) case height

906 mm

Master (outer) case gross weight

4.2 kg

Shipping (inner) case width

10.4 cm

Shipping (inner) case length

21.6 cm

Shipping (inner) case height

18.5 cm

Shipping (inner) case gross weight

2 kg

Export Control Classification Number (ECCN)

EAR99

Other features

Country of origin

Taiwan

Packaging content

1 - 130W GaN USB-C® 4-Port Charger 1 - Quick Installation Guide (QIG)

Package type

Box

Compatibility

Smartphones: iPhone® 13, 13 mini, 13 pro, 13 pro max, 12 mini, 12, 12 Pro, 12 Pro Max, 11, 11 Pro, 11 Pro Max, XS Max, XR, XS, X, 8, 8 Plus Samsung® Galaxy™ Note10, Note10+, Note9, Note8, S22 Ultra, S22+, S22, S21 FE, S21 Ultra, S21, S20 FE, S20 Ultra, S20, S10, S10+, S10 Lite, S10 5G, S10e, S9+, S9, S8, S8+ Pixel™ 4, 4a, 4XL, 5, 5a, 6, 6a, 6 Pro Sony® Xperia® XZ3 LG™ G8 ThinQ™, LG™ 7 Tablets: iPad Air® 10.5'", iPad Pro® 11''/12.9" Samsung® Galaxy™ Tab S8 Ultra, S8+, S8, S7 FE, S7+, S7, S6 Lite, S6, S5e, S4 Google Pixel™ tablets Consoles: Nintendo Switch™ Nintendo Switch™ Lite Stream Deck™ *Not compatible with the Nintendo Switch™ dock. Laptops: MacBook Air® 13'', MacBook® 12'', MacBook Pro® 13'', MacBook Pro® 15", MacBook Pro® 16", M1 MacBook® computers Microsoft® Surface™ computers with power delivery Dell™ XPS™ 13, XPS™ 15, Inspiron™ 13, Inspiron™ 7000, Dell™ Vostro™ 5471 HP® Elite X2, EliteBook X360, Spectre® 13, Spectre® 15, Spectre® 360, Spectre® folio 13-ak0000tu, Chromebook™ computers Lenovo™ ThinkPad® X1, Yoga™ *Note: Compatibility is not limited to just the device listed

Technical features

The first and the second USB-C® port provide up to 100W of power when used independently. The first and the second USB-C® port provide up to 65W of power when both ports are used. 【Dynamic Power Control of full load in 30mins : PD90W(PD45W+PD45W)】 The third USB-C® port provides up to 20W of power when used independently. The USB™ Type-A port provides up to 18W of power when used independently. The third USB-C® and USB™ Type-A port provide up to 20W (5V/2A+5V/2A) of power when used both ports.
