Zyxel none Nebula NR7101 5G NR OUTDOOR UNIT
In Stock
|
Call For Price
(0808 189 1246)
Technical details
Mounting
Wall mounting
Device type
Cellular network router
Data network
4G- 5G- LTE
Package width
280 mm
Package weight
2.82 kg
Package height
108 mm
Package depth
420 mm
Harmonized System (HS) code
85176990
Ethernet LAN features
Ethernet LAN (RJ-45) ports
1
Ethernet LAN
Yes
Ethernet LAN interface type
Gigabit Ethernet
Networking standards
IEEE 802.3af- IEEE 802.3at
DHCP server
Yes
Cellular interface
Number of SIM cards
2
4G standard
LTE-TDD & LTE-FDD
Design
Mounting
Wall mounting
Device type
Cellular network router
Product colour
White
Suitable for outdoor use
Yes
Reset button
Yes
LED indicators
Yes
Wireless LAN features
Wi-Fi
Yes
Wi-Fi standards
802.11b- 802.11g- Wi-Fi 4 (802.11n)
WLAN data transfer rates supported
300 Mbit/s
Wi-Fi frequency
2.4 GHz
Mobile network
Number of SIM cards
2
Data network
4G- 5G- LTE
4G standard
LTE-TDD & LTE-FDD
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
USB port
No
Security
Port forwarding
Yes
IP address filtering
Yes
Security algorithms
SSH
Firewall
Yes
URL filtering
Yes
DMZ support
Yes
VPN support
Virtual Private Network (VPN) pass-through
Certificates
Certification
CE- WEEE- RoHS- HSF
Packaging content
Cables included
LAN (RJ-45)
Performance
Certification
CE- WEEE- RoHS- HSF
Mobile operating systems supported
Android- iOS
Management features
Web-based management
Yes
Management protocols
APN- PIN/PUK- MQTT
Antenna
Antenna gain level (max)
10 dBi
Antenna type
Internal
Antennas quantity
6
Power
Power consumption (typical)
16 W
Power source type
PoE
Operational conditions
Storage temperature (T-T)
-40 - 65 °C
Storage relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Weight
1.14 kg
Width
255 mm
Depth
256 mm
Height
58 mm
Packaging data
Cables included
LAN (RJ-45)
Package width
280 mm
Package weight
2.82 kg
Package height
108 mm
Package depth
420 mm
Logistics data
Harmonized System (HS) code
85176990
Zyxel none Nebula NR7101 5G NR OUTDOOR UNIT
