StarTech.com 4-Port PCI Express RS232 Serial Adapter Card - 16950 UART - 256-byte FIFO Cache - ASIX AX99100 - Full Profile Bracket - Replacement for PEX4S952 (PEX4S953)
In Stock
|
Call For Price
(0808 189 1246)
Ports & interfaces
Internal
Yes
Output interface
Serial
Serial interface type
RS-232
Serial ports quantity
4
Host interface
PCIe
Expansion card form factor
Full-height / Low-profile
Technical details
Chipset
Asix AX99100
FIFO (First In- First Out)
256 B
Sustainability certificates
RoHS
Performance
Stop bits
1-1.5-2
Data bits
5-6-7-8-9
Baud rate
921.6 Kbit/s
Chipset
Asix AX99100
FIFO (First In- First Out)
256 B
Product colour
Green
Certificates
Certification
CE- FCC- Microsoft WHQL
Colour
Product colour
Green
Design
Mean time between failures (MTBF)
214358 h
Internal
Yes
Product colour
Green
Certification
CE- FCC- Microsoft WHQL
Features
Stop bits
1-1.5-2
Data bits
5-6-7-8-9
Baud rate
921.6 Kbit/s
Chipset
Asix AX99100
FIFO (First In- First Out)
256 B
Parity bit
Even- Mark- N- Odd- Space
Flow Control type
N- RTS/CTS- XON/XOFF
Operational conditions
Operating temperature (T-T)
-10 - 80 °C
Storage temperature (T-T)
-20 - 100 °C
Operating relative humidity (H-H)
5 - 85%
Weight & dimensions
Width
63 mm
Depth
75 mm
Height
15 mm
Weight
50 g
StarTech.com 4-Port PCI Express RS232 Serial Adapter Card - 16950 UART - 256-byte FIFO Cache - ASIX AX99100 - Full Profile Bracket - Replacement for PEX4S952 (PEX4S953)
