Intel R2308WFTZSR server barebone Intel® C624 LGA 3647 (Socket P) Rack (2U) Black, Silver

RAID levels

0- 1- 10

Hot-swap HDD bays

Yes

Optical drive type

No

Compatible operating systems

Windows Server 2016*|Ubuntu*

Built-in processor

No

Processor socket

LGA 3647 (Socket P)

Number of processors supported

2

Motherboard chipset

Intel® C624

Compatible processor series

Intel® Xeon®

Product type

System

Product series

Intel® Server System R2000WF Family

Product codename

Wolf Pass

Rack-Friendly board

Yes

Rack rails

No

LED indicators

Yes

Heat sink included

Yes

Heat sink

(2) FXXCA78X108HS

Product colour

Black- Silver

Chassis type

Rack (2U)

Cooling type

Active

Supported memory types

DDR4-SDRAM

Number of DIMM slots

24

Maximum internal memory

6000 GB

Number of storage drives supported

10

Number of 3.5" bays

8

Supported storage drive interfaces

M.2- Serial ATA III

RAID levels

0- 1- 10

Hot-swap HDD bays

Yes

Storage drive sizes supported

2.5-3.5"

Supported storage drive types

HDD & SSD

SSD form factor

M.2

Intel Quiet System Technology (QST)

Yes

Intel Flex Memory Access

Yes

Intel Fast Memory Access

Yes

Intel Rapid Storage Technology enterprise

Yes

Internal I/O Expansion Module x8 Gen 3

1

Intel Server Customization Technology

Yes

Intel Quiet Thermal Technology

Yes

Intel Efficient Power Technology

Yes

Intel Build Assurance Technology

Yes

Intel Advanced Management Technology

Yes

Trusted Platform Module (TPM) version

2.0

Trusted Platform Module (TPM)

Yes

Optical drive type

No

Intel Remote Management Module Support

Yes

Intel On-Demand Power Redundancy Technology

Yes

Intel Intelligent Power Node Manager

Yes

Compatible operating systems

Windows Server 2016*|Ubuntu*

Ethernet LAN data rates

10-100-1000-10000 Mbit/s

Ethernet LAN

Yes

Ethernet interface type

10 Gigabit Ethernet- Gigabit Ethernet

USB ports quantity

5

Serial ports quantity

2

Number of SATA connectors

10

Ethernet LAN (RJ-45) ports

3

PCI Express x8 (Gen 3.x) slots

3

PCI Express x4 (Gen 3.x) slots

1

PCI Express x16 (Gen 3.x) slots

2

PCI Express x24 Riser Super slots

2

PCI Express OCuLink connectors (NVMe support)

4

Trusted Platform Module (TPM) version

2.0

Trusted Platform Module (TPM)

Yes

Optical drive type

No

Compatible operating systems

Windows Server 2016*|Ubuntu*

Harmonized System (HS) code

84714100

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

G157815L2

Number of UPI links

2

Intel® Optane™ DC Persistent Memory technology

Yes

Intel Node Manager

Yes

Backplanes

Included

Intel® Optane™ DC Persistent Memory Supported

Yes

Product codename

Wolf Pass

USB ports quantity

5

Product type

System

PCI Express x8 (Gen 3.x) slots

3

PCI Express x4 (Gen 3.x) slots

1

PCI Express x16 (Gen 3.x) slots

2

Packaging content

(1) 2U Chassis with Quick Reference Label affixed to top cover (1) Intel® Server Board S2600WFTR (dual 10 GbE LAN) S2600WFTR (2) PCIe Riser card brackets. Includes: (2) 3-slot PCIe* riser cards A2UL8RISER2 (1) 2-slot low profile PCIe* riser card A2UX8X4RISER (8) 3.5” hot-swap drive bays with drive carriers and blanks. Includes: (1) 12Gb SAS backplane A2U8X35S3HSDK1 (8) 3.5” hot-swap drive tool less carriers FXX35HSCAR2 (1) Standard control panel assembly *300 mm front panel cable H34381-xxx (1) Front I/O panel assembly o 620 mm USB 3.0 cable H76899-xxx o 400 mm video cable H62114-xxx (1) 400 mm Backplane power cable (1) SATA optical drive power cable 300 mm H23901-001 (1) SATA optical drive bay mounting kit (1) Standard 2U air duct (6) Hot swap system fans FR2UFAN60HSW (8) DIMM slot blanks

Number of storage drives supported

10

Number of 3.5" bays

8

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Server Customization Technology

Yes

Intel Quiet Thermal Technology

Yes

Intel Efficient Power Technology

Yes

Intel Build Assurance Technology

Yes

Intel Advanced Management Technology

Yes

Trusted Platform Module (TPM) version

2.0

Trusted Platform Module (TPM)

Yes

Rack-Friendly board

Yes

Rack rails

No

Intel Remote Management Module Support

Yes

Intel On-Demand Power Redundancy Technology

Yes

Intel Intelligent Power Node Manager

Yes

Heat sink included

Yes

Heat sink

(2) FXXCA78X108HS

CPU configuration (max)

2

Chassis type

Rack (2U)

Target market

Mainstream

Supported RAID configuration

SW RAID 0- 1- 10- optional 5

Supported board

Intel Server Board S2600WFTR

Status

Launched

Riser slot 2 number of lanes

24

Riser slot 1 number of lanes

24

Redundant fans

Yes

Optical drive supported

Yes

Launch date

Q2'19

Included riser slot 1 configuration(s)

3x PCIe Gen3 x8

Extended warranty available for purchase (select countries)

Yes

Expected discontinuance date

2023

Riser slot 3 number of lanes

12

Riser Slot 2 configuration

3x PCIe Gen3 x8

PCI Express x24 Riser Super slots

2

Riser slot 3 configuration

1x PCIe Gen3 x8 + 1x PCIe Gen2 x4

Harmonized System (HS) code

84714100

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

G157815L2

Product colour

Black- Silver

LED indicators

Yes

Intel Quiet System Technology (QST)

Yes

Intel Flex Memory Access

Yes

Intel Fast Memory Access

Yes

Intel Rapid Storage Technology enterprise

Yes

Internal I/O Expansion Module x8 Gen 3

1

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Server Customization Technology

Yes

Intel Quiet Thermal Technology

Yes

Intel Efficient Power Technology

Yes

Intel Build Assurance Technology

Yes

Intel Advanced Management Technology

Yes

Intel Remote Management Module Support

Yes

Intel On-Demand Power Redundancy Technology

Yes

Intel Intelligent Power Node Manager

Yes

Intel® Optane™ Memory Ready

No

Number of main power supplies

1

Redundant power supply (RPS) support

Yes

Power supply type

AC

Power supply

1300 W

Number of power supply units

1

Thermal Design Power (TDP)

205 W

Width

430 mm

Height

87.4 mm

Depth

710 mm

Packaging content

(1) 2U Chassis with Quick Reference Label affixed to top cover (1) Intel® Server Board S2600WFTR (dual 10 GbE LAN) S2600WFTR (2) PCIe Riser card brackets. Includes: (2) 3-slot PCIe* riser cards A2UL8RISER2 (1) 2-slot low profile PCIe* riser card A2UX8X4RISER (8) 3.5” hot-swap drive bays with drive carriers and blanks. Includes: (1) 12Gb SAS backplane A2U8X35S3HSDK1 (8) 3.5” hot-swap drive tool less carriers FXX35HSCAR2 (1) Standard control panel assembly *300 mm front panel cable H34381-xxx (1) Front I/O panel assembly o 620 mm USB 3.0 cable H76899-xxx o 400 mm video cable H62114-xxx (1) 400 mm Backplane power cable (1) SATA optical drive power cable 300 mm H23901-001 (1) SATA optical drive bay mounting kit (1) Standard 2U air duct (6) Hot swap system fans FR2UFAN60HSW (8) DIMM slot blanks

Product type

System

On-board graphics card

No

CPU configuration (max)

2

Product series

Intel® Server System R2000WF Family

Product codename

Wolf Pass

Target market

Mainstream

Supported RAID configuration

SW RAID 0- 1- 10- optional 5

Supported board

Intel Server Board S2600WFTR

Status

Launched

Riser slot 2 number of lanes

24

Riser slot 1 number of lanes

24

Redundant fans

Yes

Optical drive supported

Yes

Launch date

Q2'19

Included riser slot 1 configuration(s)

3x PCIe Gen3 x8

Extended warranty available for purchase (select countries)

Yes

Expected discontinuance date

2023

Riser slot 3 number of lanes

12

Riser Slot 2 configuration

3x PCIe Gen3 x8

Riser slot 3 configuration

1x PCIe Gen3 x8 + 1x PCIe Gen2 x4
