Printing

Type

Mobile printer

Print technology

Direct thermal

Print speed

6 ips

Print speed

152 mm/sec

Maximum resolution

203 x 203 DPI

Performance

Type

Mobile printer

Print technology

Direct thermal

Print speed

6 ips

Print speed

152 mm/sec

Maximum resolution

203 x 203 DPI

Built-in barcodes

AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, ITF, MaxiCode, Micro QR Code, PDF417, POSTNET, QR Code, UPC-A, UPC-E

Paper handling

Maximum media length

100 cm

Media thickness

0.058 - 0.09 mm

Supported paper width

58 mm

Maximum roll diameter

4 cm

Maximum printing width

5.4 cm

Ports & interfaces

Standard interfaces

Bluetooth, USB 2.0

Connectivity technology

Wired & Wireless

USB 2.0 ports quantity

1

Bluetooth version

2.1+EDR

Bluetooth

Yes

USB port

Yes

USB connector

Mini-USB Type-B

Network

Ethernet LAN

No

Wi-Fi

No

Print technology

Type

Mobile printer

Print technology

Direct thermal

Print speed

6 ips

Print speed

152 mm/sec

Print quality

Maximum media length

100 cm

Maximum resolution

203 x 203 DPI

Maximum printing width

5.4 cm

Technical details

Maximum media length

100 cm

International Protection (IP) code

IP54

Media thickness

0.058 - 0.09 mm

Windows operating systems supported

Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate

Mobile operating systems supported

Android, iOS

Maximum printing width

5.4 cm

Product colour

Grey

Built-in barcodes

AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, ITF, MaxiCode, Micro QR Code, PDF417, POSTNET, QR Code, UPC-A, UPC-E

Products per pallet

216 pc(s)

Layers per pallet

6 pc(s)

Master (outer) cases per pallet

72 pc(s)

Pallet gross weight

295.9 kg

Pallet gross height

16.5 cm

Country of origin

China

Master (outer) cases per pallet layer

12 pc(s)

Harmonized System (HS) code

84433210

Pallet type

800 x 1200 mm

Features

International Protection (IP) code

IP54

Media thickness

0.058 - 0.09 mm

Internal memory

32 MB

Flash memory

32 MB

Product colour

Grey

Built-in barcodes

AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, ITF, MaxiCode, Micro QR Code, PDF417, POSTNET, QR Code, UPC-A, UPC-E

Country of origin

China

Design

Display diagonal

6.1 cm (2.4")

Product colour

Grey

Built-in display

Yes

Display

LCD

Display

Display diagonal

6.1 cm (2.4")

Built-in display

Yes

Display

LCD

Memory

Internal memory

32 MB

Flash memory

32 MB

Power

Rechargeable

Yes

Battery voltage

7.2 V

Battery technology

Lithium-Ion (Li-Ion)

Operational conditions

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-10 - 50 °C

Operating relative humidity (H-H)

10 - 90%

System requirements

Windows operating systems supported

Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate

Mobile operating systems supported

Android, iOS

Weight & dimensions

Width

125 mm

Depth

185 mm

Height

230 mm

Package weight

1.37 kg

Weight

872 g

Packaging data

Package weight

1.37 kg

Packaging content

Quick start guide

Yes

Batteries included

Yes

Software

Windows operating systems supported

Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate

Mobile operating systems supported

Android, iOS

Logistics data

Products per pallet

216 pc(s)

Layers per pallet

6 pc(s)

Master (outer) cases per pallet

72 pc(s)

Pallet gross weight

295.9 kg

Pallet gross height
