Printing

Type

Mobile printer

Print technology

Direct thermal

Print speed

5 ips

Print speed

127 mm/sec

Maximum resolution

203 x 203 DPI

Performance

Type

Mobile printer

Print technology

Direct thermal

Print speed

5 ips

Print speed

127 mm/sec

Maximum resolution

203 x 203 DPI

Paper handling

Maximum media length

3 m

Supported paper width

45 - 113 mm

Maximum roll diameter

5.8 cm

Maximum printing width

10.4 cm

Ports & interfaces

Bluetooth profiles

GATT, HCRP, OPP, SPP

Standard interfaces

Bluetooth, NFC, USB 2.0

Connectivity technology

Wired & Wireless

USB 2.0 ports quantity

1

Bluetooth version

4.2

Bluetooth

Yes

USB port

Yes

USB connector

Mini-USB Type-B

Near Field Communication (NFC)

Yes

Network

Ethernet LAN

No

Wi-Fi

No

Print technology

Type

Mobile printer

Print technology

Direct thermal

Print speed

5 ips

Print speed

127 mm/sec

Print quality

Maximum media length

3 m

Maximum resolution

203 x 203 DPI

Maximum printing width

10.4 cm

Technical details

Maximum media length

3 m

International Protection (IP) code

IP54

Bluetooth profiles

GATT, HCRP, OPP, SPP

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64

Maximum printing width

10.4 cm

Product colour

Black

Products per pallet

168 pc(s)

Layers per pallet

7 pc(s)

Master (outer) cases per pallet

56 pc(s)

Pallet gross weight

244.2 kg

Pallet gross height

16.6 cm

Country of origin

China

Master (outer) cases per pallet layer

8 pc(s)

Harmonized System (HS) code

84433210

Pallet type

800 x 1200 mm

Features

International Protection (IP) code

IP54

RAM capacity

0.256 GB

Flash memory

64 MB

Product colour

Black

Country of origin

China

Design

Product colour

Black

Built-in display

Yes

Display

LCD

Display

Built-in display

Yes

Display

LCD

Memory

RAM capacity

0.256 GB

Flash memory

64 MB

Power

Rechargeable

Yes

AC input voltage

110/220 V

AC input frequency

50 - 60 Hz

Power source type

Battery, DC

Battery technology

Lithium-Ion (Li-Ion)

Battery recharge time

4 h

Operational conditions

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

-20 - 55 °C

Operating relative humidity (H-H)

10 - 90%

System requirements

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64

Weight & dimensions

Width

121 mm

Depth

247 mm

Height

187 mm

Package weight

1.28 kg

Weight

700 g

Packaging data

Package weight

1.28 kg

Packaging content

Batteries included

Yes

Software

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64

Logistics data

Products per pallet

168 pc(s)

Layers per pallet

7 pc(s)

Master (outer) cases per pallet

56 pc(s)

Pallet gross weight

244.2 kg

Pallet gross height

16.6 cm

Harmonized System (HS) code
