Synology RackStation RS1219+ NAS/storage server Ethernet LAN Rack (2U) Black
In Stock
|
Call For Price
(0808 189 1246)
Storage
Online RAID migration
Yes
Online RAID expansion
Yes
Storage drives installed
No
Installed storage drive type
No
Supported storage drive types
HDD & SSD
Number of storage drives supported
8
Hot-swap drive bays
Yes
RAID support
Yes
Supported file systems
BTRFSFATHFS+NTFSext3ext4
RAID levels
015610JBOD
Supported storage drive interfaces
Serial ATA
Storage drive sizes supported
2.53.5"
Processor
Processor manufacturer
Intel
Thermal Design Power (TDP)
15 W
Stepping
B0
Processor threads
4
Processor socket
BGA 1283
Processor package size
34 x 28 mm
Processor operating modes
32-bit 64-bit
Processor lithography
22 nm
Processor code
SR1S9
Processor cache type
L3
Processor cache
2 MB
Physical Address Extension (PAE)
36 bit
PCI Express slots version
2
ECC supported by processor
Yes
Maximum internal memory supported by processor
64 GB
Conflict-Free processor
No
Processor ARK ID
77981
Processor frequency
2.4 GHz
Processor family
Intel Atom
Processor model
C2538
Processor cores
4
Memory
Internal memory type
DDR3
Internal memory
2 GB
Maximum RAM supported
16 GB
Memory slots
2
Network
Link aggregation
Yes
Ethernet LAN
Yes
Ethernet LAN data rates
101001000 Mbit/s
Wi-Fi
No
Wake-on-LAN ready
Yes
iSCSI support
Yes
Ports & interfaces
USB port
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Ethernet LAN (RJ-45) ports
4
eSATA ports quantity
1
Hard drive
RAID support
Yes
Supported file systems
BTRFSFATHFS+NTFSext3ext4
RAID levels
015610JBOD
Design
Cooling type
Active
Fan diameter
3.15" (8 cm)
Product colour
Black
Number of fans
2 fan(s)
LED indicators
Alarm HDD Power Status
Chassis type
Rack (2U)
Technical details
Type
NAS
Device class
Small & Medium Business
Backup function
Yes
Backup features
Cloud iSCSI LUN
Product colour
Black
Number of users
2048 user(s)
Noise level
36.8 dB
Multilingual support
Yes
LED indicators
Alarm HDD Power Status
Chassis type
Rack (2U)
Number of fans
2 fan(s)
Sustainability certificates
RoHS
Performance
System log
Yes
Type
NAS
Device class
Small & Medium Business
Backup function
Yes
Backup features
Cloud iSCSI LUN
On/off switch
Yes
Web-based management
Yes
Reset button
Yes
Operating system installed
DiskStation Manager
Number of users
2048 user(s)
Noise level
36.8 dB
Multilingual support
Yes
Access Control List (ACL)
Yes
Cooling
Cooling type
Active
Fan diameter
3.15" (8 cm)
Number of fans
2 fan(s)
Security
Access Control List (ACL)
Yes
Software
Windows operating systems supported
Windows 10Windows 7
Operating system installed
DiskStation Manager
Management features
On/off switch
Yes
Web-based management
Yes
Reset button
Yes
Power
Power consumption (HDD standby)
29.04 W
Power supply location
Built-in
Power supply unit (PSU) capacity
250 W
AC input voltage
100-240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
60.31 W
Number of power supply units
1
Weight & dimensions
Width
19" (481.9 mm)
Depth
12.1" (306.6 mm)
Height
3.46" (88 mm)
Weight
15.2 lbs (6.9 kg)
Packaging content
Quick installation guide
Yes
Cables included
AC
Processor special features
UART
Yes
Physical Address Extension (PAE)
Yes
Maximum number of PCI Express lanes
16
Intel Turbo Boost Technology
No
Intel Hyper Threading Technology (Intel HT Technology)
No
Intel AES New Instructions (Intel AES-NI)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel QuickAssist Technology
No
Intel 64
Yes
Graphics & IMC lithography
22 nm
Execute Disable Bit
Yes
Embedded options available
Yes
Memory channels supported by processor
Dual
Memory types supported by processor
DDR3-SDRAMDDR3L-SDRAM
System requirements
Windows operating systems supported
Windows 10Windows 7
Operational conditions
Storage temperature (T-T)
-20 - 60 °C
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
5 - 95%
Certificates
Certification
EAC VCCI RCM FCC CE BSMI
Packaging data
Cables included
AC
Other features
Processor ARK ID
77981
Synology RackStation RS1219+ NAS/storage server Ethernet LAN Rack (2U) Black
| Length | 30.66 cm |
| Width | 48.19 cm |
| Height | 8.80 cm |
| Weight | 6.890000 kgs |
