APC Smart-UPS 750VA uninterruptible power supply UPS

Output voltage regulation

5%

Output frequency regulation

+/- 3 Hz

Output power

500 W

Input operation voltage (min)

151 V

Input operation voltage (max)

302 V

Output operation voltage (min)

220 V

Output operation voltage (max)

240 V

Surge energy rating

459 J

Emergency Power Off (EPO)

O

Output power capacity

0.75 kVA

Audible alarm modes

Battery replacement

UPS topology

Line-Interactive

Waveform

Sine

Auto-restart

Yes

Response time

2 ms

LED indicators

Yes

Surge protection

Yes

Noise level

46 dB

Audible alarm(s)

Yes

Output frequency

50/60 Hz

Web-based management

Yes

Audible alarm modes

Battery replacement

UPS topology

Line-Interactive

Waveform

Sine

Output voltage regulation

5%

Output frequency regulation

+/- 3 Hz

Auto-restart

Yes

Response time

2 ms

Output power

500 W

Input operation voltage (min)

151 V

Input operation voltage (max)

302 V

Output operation voltage (min)

220 V

Output operation voltage (max)

240 V

Surge energy rating

459 J

Surge protection

Yes

Emergency Power Off (EPO)

O

Noise level

46 dB

Audible alarm(s)

Yes

Output power capacity

0.75 kVA

Input frequency

50/60 Hz

AC outlets quantity

4 AC outlet(s)

AC outlet types

C13 coupler, C14 coupler

Power plug

C14 coupler

USB 2.0 ports quantity

1

Ethernet LAN (RJ-45) ports

1

Battery capacity

168 Ah

Battery technology

Sealed Lead Acid (VRLA)

Battery recharge time

3 h

Hot-swap battery

Yes

Cold start

Yes

Automatic battery test

Yes

Rack capacity

2U

Form factor

Rackmount

LED indicators

Yes

Product colour

Black

Certification

CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE

Display type

LCD

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-15 - 45 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Operating altitude

0 - 3000 m

Non-operating altitude

0 - 15000 m

Output voltage

230 V

Output frequency

50/60 Hz

Sustainability certificates

Green Premium

Harmonized System (HS) code

85078000

Total carbon footprint (kg of CO2e)

497.38

Compliance certificates

RoHS

Certification

CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE

Compliance certificates

RoHS

Web-based management

Yes

Quick installation guide

Yes

Cables included

Input power cable, USB cable

Rack mount kit

Yes

Resource CD

Yes

Sustainability certificates

Green Premium

Package width

546 mm

Package depth

584 mm

Package height

241 mm

Weight

17.2 kg

Width

432 mm

Package weight

21.2 kg

Height

89 mm

Depth

406 mm

Quick installation guide

Yes

Cables included

Input power cable, USB cable

Resource CD

Yes

Rack mount kit

Yes

Package width

546 mm

Package depth

584 mm

Package height

241 mm

Package weight

21.2 kg

Products per pallet

16 pc(s)

Harmonized System (HS) code

85078000

Total carbon footprint (kg of CO2e)

497.38

Output voltage

230 V
