Supermicro SuperServer 1029UZ-TN20R25M
In Stock
|
Call For Price
(0808 189 1246)
SPECIFICATIONS
Product Description
Supermicro SuperServer 1029UZ-TN20R25M - rack-mountable
Type
Server - rack-mountable
Height (Rack Units)
1U
Server Scalability
2-way
Processor
No CPU
Processor Socket
Socket P
RAM
0 GB (installed) / 6 TB (max) - DDR4 SDRAM - ECC
Storage Controller
RAID (SATA 6Gb/s); NVMe (PCI Express)
Server Storage Bays
Hot-swap 2.5"
Hard Drive
No HDD
Optical Storage
No optical drive
Graphics Controller
ASPEED AST2500
Networking
25 Gigabit LAN
Power
AC 120/230 V (50 - 60 Hz)
Power Redundancy
Yes
OS Provided
No operating system
Color
Black
Dimensions (WxDxH)
17.2 in x 27.8 in x 1.7 in
Weight
48.06 lbs
General
Type
Server
Product Form Factor
Rack-mountable - 1U
Server Scalability
2-way
Hot-Swap Bays Qty
20
Color
Black
Processor / Chipset
CPU
No CPU
Max CPU Qty
2
CPU Upgradability
Upgradable
CPU Socket
Socket P
Chipset Type
Intel C621
Motherboard Name
Supermicro X11DPU-ZE+
RAM
Installed Size
0 GB / 6 TB (max)
Technology
DDR4 SDRAM - ECC
Form Factor
DIMM 288-pin
Slots
24 (total) / 24 (empty)
Hard Drive
Type
No HDD
Storage Controller
Type
1 x RAID
Controller Interface Type
SATA 6Gb/s
RAID Level
RAID 0 RAID 1 RAID 5 RAID 10
Storage Controller (2nd)
Type
NVMe
Controller Interface Type
PCI Express
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
ASPEED AST2500
Video Interfaces
VGA
Networking
Ethernet Ports
2 x SFP28
Data Link Protocol
25 Gigabit Ethernet
Remote Management Protocol
IPMI 2.0
Features
ACPI support KVM over IP support
Expansion / Connectivity
Bays
20 (total) / 20 (free) x hot-swap 2.5"
Miscellaneous
Included Accessories
2 x CPU Heatsink 2 x riser cards
Compliant Standards
RoHS
Power
Device Type
Power supply
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 120/230 V (50 - 60 Hz)
Power Provided
1600 Watt
80 PLUS Certification
80 PLUS Titanium
Efficiency
0.96
Operating System / Software
OS Provided
No operating system
Dimensions & Weight
Width
17.2 in
Depth
27.8 in
Height
1.7 in
Weight
48.06 lbs
Supermicro SuperServer 1029UZ-TN20R25M
| Length | 27.8 cm |
| Width | 17.2 cm |
| Height | 1.7 cm |
| Weight | 1.000000 kgs |
