Storage

Online RAID migration

Yes

Online RAID expansion

Yes

Bad block scan

Yes

Storage drives installed

Installed storage drive type

Supported storage drive types

HDD & SSD

Number of storage drives supported

Hot-swap drive bays

Yes

RAID support

Yes

Supported file systems

FAT32-HFS+-NTFS-ZFS-ext3-ext4

RAID levels

0-1-5-6-10-50-60

Supported storage drive interfaces

Serial ATA II- Serial ATA III

Storage drive sizes supported

2.5-3.5"

RAID rebuild

Yes

Processor

Processor manufacturer

Intel

Tjunction

105 Â°C

Thermal Design Power (TDP)

40 W

Tcase

83 Â°C

Scalability

Processor threads

Processor package size

37.5 x 37.5 mm

Processor operating modes

64-bit

Processor lithography

14 nm

Processor cache

6 MB

Processor boost frequency

3.2 GHz

PCI Express slots version

2.0-3.0

On-board graphics adapter model

Not available

CPU configuration (max)

Maximum internal memory supported by processor

128 GB

Processor ARK ID

193687

Processor frequency

2.6 GHz

Processor family

IntelÂ® XeonÂ® D

Processor model

D-1622

Processor cores

Memory

Internal memory type

DDR4

Internal memory

32 GB

Maximum RAM supported

128 GB

Memory slots

Flash memory

5000 MB

Memory form factor

UDIMM

Network

Load balancing system

Yes

Link aggregation

Yes

Dynamic DNS (DDNS)

Yes

Ethernet LAN

Yes

Ethernet LAN data rates

1000-10000 Mbit/s

Wake-on-LAN ready

Yes

Supported network protocols

FTP- SFTP- TFTP

Jumbo frames support

Yes

iSCSI support

Yes

DHCP server

Yes

DHCP client

Yes

WLAN adapter supported

Yes

Ports & interfaces

USB port

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

PCI Express x8 (Gen 3.x) slots

PCI Express x4 (Gen 3.x) slots

Fiber ports quantity

Fiber optic connector

SFP+

Ethernet LAN (RJ-45) ports

Hard drive

RAID support

Yes

Supported file systems

FAT32-HFS+-NTFS-ZFS-ext3-ext4

RAID levels

0-1-5-6-10-50-60

Graphics

On-board graphics adapter model

Not available

Design

Cooling type

Active

Fan diameter

6 cm

Product colour

Black- Grey

Number of fans

3 fan(s)

LED indicators

HDD- LAN- SSD- Status

Chassis type

Rack (2U)

Technical details

Type

NAS

Device class

Large Enterprise Business

Product colour

Black- Grey

Noise level

56.9 dB

Multilingual support

Yes

LED indicators

HDD- LAN- SSD- Status

Chassis type

Rack (2U)

Buzzer

Yes

Number of fans

3 fan(s)

Performance

Built-in FTP server

Yes

System log

Yes

S.M.A.R.T. support

Yes

Hot spare

Yes

Browser supported

Apple Safari 7+- Google Chrome- Microsoft Internet Explorer 10+- Mozilla Firefox

Universal Plug and Play (UPnP)

Yes

Type

NAS

Device class

Large Enterprise Business

On/off switch

Yes

Windows operating systems supported

Windows 10-Windows 7-Windows 8

Server operating systems supported

Windows Server 2008 R2-Windows Server 2012-Windows Server 2012 R2-Windows Server 2016-Windows Server 2019

Mac operating systems supported

Mac OS X 10.10 Yosemite- Mac OS X 10.11 El Capitan- Mac OS X 10.12 Sierra- Mac OS X 10.13 High Sierra- Mac OS X 10.14 Mojave- Mac OS X 10.15 Catalina- Mac OS X 10.15.3 Catalina

Linux operating systems supported

Yes

Web-based management

Yes

Security algorithms

256-bit AES-FIPS 140-2-HTTPS-SSH-SSL/TLS

Reset button

Yes

Operating system version

4.5.0

Operating system installed

QuTS hero

Noise level

56.9 dB

Multilingual support

Yes

Buzzer

Yes

Access Control List (ACL)

Yes

Snapshot

Yes

Cooling

Cooling type

Active

Fan diameter

6 cm

Fan voltage

12 V

Number of fans

3 fan(s)

Security

Security algorithms

256-bit AES-FIPS 140-2-HTTPS-SSH-SSL/TLS

Access Control List (ACL)

Yes

Software

Windows operating systems supported

Windows 10-Windows 7-Windows 8

Server operating systems supported

Windows Server 2008 R2-Windows Server 2012-Windows Server 2012 R2-Windows Server 2016-Windows Server 2019

Mac operating systems supported

Mac OS X 10.10 Yosemite- Mac OS X 10.11 El Capitan- Mac OS X 10.12 Sierra- Mac OS X 10.13 High Sierra- Mac OS X 10.14 Mojave- Mac OS X 10.15 Catalina- Mac OS X 10.15.3 Catalina

Linux operating systems supported

Yes

Operating system version

4.5.0

Operating system installed

QuTS hero

Management features

On/off switch

Yes

Web-based management

Yes

Reset button

Yes

Power

Power supply location

Built-in

Power supply unit (PSU) capacity

550 W

Fan voltage

12 V

AC input voltage

100 - 240 V

Power consumption (typical)

117.92 W

Number of power supply units

Weight & dimensions

Width

482 mm

Depth

549.7 mm

Height

88.3 mm

Weight

12.7 kg

Package weight

18.7 kg

Packaging content

Number of screws

112

Cables included

AC- LAN (RJ-45)

Processor special features

Thermal Monitoring Technologies

Yes

Maximum number of PCI Express lanes

IntelÂ® Turbo Boost Technology

2.0

IntelÂ® Secure Key

Yes

IntelÂ® OS Guard

Yes

IntelÂ® Hyper Threading Technology (IntelÂ® HT Technology)

Yes

IntelÂ® AES New Instructions (IntelÂ® AES-NI)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel TSX-NI

Yes

Intel Trusted Execution Technology

Yes

Intel QuickAssist Technology

Intel 64

Yes

Idle States

Yes

Execute Disable Bit

Yes

Enhanced Intel SpeedStep Technology

Yes

Embedded options available

Memory types supported by processor

DDR3-SDRAM-DDR4-SDRAM

System requirements

Windows operating systems supported

Windows 10-Windows 7-Windows 8

Server operating systems supported

Windows Server 2008 R2-Windows Server 2012-Windows Server 2012 R2-Windows Server 2016-Windows Server 2019

Mac operating systems supported

Mac OS X 10.10 Yosemite- Mac OS X 10.11 El Capitan- Mac OS X 10.12 Sierra- Mac OS X 10.13 High Sierra- Mac OS X 10.14 Mojave- Mac OS X 10.15 Catalina- Mac OS X 10.15.3 Catalina

Linux operating systems supported

Yes

Operational conditions

Operating temperature (T-T)

0 - 40 Â°C

Operating relative humidity (H-H)

5 - 95%

Packaging data

Package weight

18.7 kg

Cables included

AC- LAN (RJ-45)
