TP-Link VIGI C540S(4mm) Turret IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling/wall

Preset points

Yes

PTZ modes

Auto scan, Preset point

Type

IP security camera

Connectivity technology

Wired

PTZ control

Yes

Placement supported

Indoor & outdoor

Wide Dynamic Range (WDR)

Yes

Day/night mode

Yes

Certification

CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC

Form factor

Turret

Product colour

Black, White

Mounting type

Ceiling/wall

International Protection (IP) code

IP66

Housing material

Plastic

Tilt angle range

0 - 105°

Tilt speed

44 °/sec

Pan range

0 - 348°

Pan speed

44 °/sec

Camera pan control

Yes

Camera tilt control

Yes

Lens viewing angle, horizontal

104°

Lens viewing angle, vertical

55°

Lens viewing angle, diagonal

127°

Sensor type

CMOS

Optical sensor size

25.4 / 3 mm (1 / 3")

Number of sensors

1

Number of lenses

1

Detect distance

63 m

Observe distance

26 m

Recognize distance

13 m

Identify distance

6 m

Lens diameter

4 mm

Night vision

Yes

Night vision distance

30 m

LED type

IR

Image quality adjustment

Brightness, Contrast, DNR, Mirror, Saturation, Sharpness

Privacy masking

Yes

Region of Interest (ROI) encoding

Yes

Highlight Compensation (HLC)

Yes

Digital Wide Dynamic Range (DWDR)

Yes

Bit rate

256 Kbps - 6 Mbps

Back Light Compensation (BLC)

Yes

Video compression formats

H.264, H.264+, H.265, H.265+

Maximum resolution

2688 x 1520 pixels

Supported graphics resolutions

320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520

Frame rate

30 fps

Video streaming

Yes

Total megapixels

4 MP

Audio input channels

1.0 channels

Audio output channels

1.0 channels

Built-in speaker(s)

Yes

Built-in microphone

Yes

Audio system

2-way

Sample rates

0 - 8 kHz

Bit rate range

0 - 64 Kbit/s

Bluetooth

No

Ethernet interface type

Fast Ethernet

Ethernet LAN

Yes

Wi-Fi

No

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS

Number of simultaneous live view channels

3 channels

Live view

Yes

Maximum memory card size

256 GB

Card reader integrated

Yes

Built-in HDD

No

Compatible memory cards

MicroSD (TransFlash)

Ethernet LAN (RJ-45) ports

1

DC-in jack

Yes

Connectivity technology

Wired

Intelligent Video Surveillance (IVS) system features

Abandoned object, Human detection, Vehicle detection

IP address filtering

Yes

HTTPS encryption

Yes

Password protection

Yes

Mirror

Yes

Human and vehicle targets classification

Yes

Digest authentication

Yes

Web browser

Yes

Reset button

Yes

Behavior analysis

Intrusion detection, Line crossing detection, Region exiting detection

Smartphone/tablet remote support

Yes

Power source type

DC, PoE

Power consumption (max)

13.13 W

Power consumption (Power over Ethernet (PoE))

16.47 W

DC-in jack

Yes

DC output voltage

12

Certification

CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC

Operating temperature (T-T)

-30 - 60 °C

Storage temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Width

120 mm

Depth

172 mm

Height

203 mm

Number of cameras

1

Video compression formats

H.264, H.264+, H.265, H.265+
