Performance

Languages support

Simplified Chinese, Czech, Danish, German, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish

Fog proof

Yes

Type

IP security camera

Connectivity technology

Wired

Placement supported

Indoor & outdoor

Wide Dynamic Range (WDR)

Yes

Day/night mode

Yes

Alarm input/output

Yes

Certification

FCC, CE

Design

Weatherproof

Yes

IK code

IK10

Fog proof

Yes

Form factor

Dome

Product colour

Ivory

Mounting type

Ceiling

Protection features

Splash proof

International Protection (IP) code

IP66

Housing material

Aluminium

Camera

White balance

ATW, AWC, Indoor, Manual, Mercury lamp, Outdoor, Sodium lamp

Camera shutter type

Electronic

Camera shutter speed

2 - 1/12000 s

Lens viewing angle, horizontal

192°

Lens viewing angle, vertical

192°

Lens viewing angle, diagonal

192°

Progressive scan

Yes

Image sensor

Number of effective pixels (H x V)

3096 x 2094 pixels

Sensor type

CMOS

Progressive scan

Yes

Optical sensor size

25.4 / 1.8 mm (1 / 1.8")

Lens system

Maximum aperture number

1.6

Focus

Manual

Zoom capability

Yes

Digital zoom

Fixed focal length

1.6 mm

Night vision

Yes

Night vision distance

15 m

LED type

Video

Noise reduction

Yes

Privacy masking

Yes

Flip & mirror

Yes

Image stabilizer

Yes

Highlight Compensation (HLC)

Yes

Back Light Compensation (BLC)

Yes

3D NR (Noise Reduction)

Yes

Video compression formats

H.264, H.265, M-JPEG

Maximum resolution

2048 x 2048 pixels

Supported graphics resolutions

640 x 480 (VGA), 704 x 576, 800 x 600 (SVGA), 960 x 960, 1024 x 768 (XGA), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 480, 2048 x 1536 (QXGA)

Supported video modes

480p, 768p, 960p

Frame rate

30 fps

Video streaming

Yes

Total megapixels

6 MP

Audio

Audio input channels

1 channels

Signal-to-Noise Ratio (SNR)

50 dB

Built-in microphone

Yes

Audio formats supported

G.711, G.726

Network

Bluetooth

Ethernet interface type

Fast Ethernet

Networking standards

IEEE 802.3af

Number of users

20 user(s)

Streaming method

Multicast, Unicast

Ethernet LAN

Yes

Cabling technology

10/100Base-T(X)

Wi-Fi

Supported network protocols

IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SIP

Storage

Maximum memory card size

512 GB

Card reader integrated

Yes

Compatible memory cards

SD, SDHC, SDXC

Ports & interfaces

Microphone in

Yes

Interface

RJ-45

Connectivity technology

Wired

Security

Alert notification type

E-mail

Video motion detection

Yes

Anti-flicker

Yes

Power

Power source type

DC, PoE

Power consumption (max)

12 W

Power consumption (Power over Ethernet (PoE))

12.95 W

Power over Ethernet (PoE)

Yes

DC output voltage

Certificates

Certification

FCC, CE

Operational conditions

Operating temperature (T-T)

-40 - 55 °C

Storage temperature (T-T)

-50 - 60 °C

Operating relative humidity (H-H)

0 - 90%

Storage relative humidity (H-H)

0 - 90%

System requirements

Mac compatibility

Yes

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

Mac operating systems supported

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra

Weight & dimensions

Height

65.8 mm

Diameter

14.6 cm

Weight

785 g

Packaging content

Number of cameras

Technical details
