Ethernet LAN features

Ethernet WAN

Yes

Ethernet LAN interface type

Fast Ethernet

Ethernet LAN

Yes

Ethernet LAN data rates

10-100 Mbit/s

Cabling technology

10/100Base-T(X)

DSL features

DSL WAN

Mobile network

SIM card slot

Yes

3G/4G USB modem compatibility

Yes

UMTS bands supported

900-2100 MHz

GSM bands supported

850-900-1800-1900 MHz

4G bands supported

800-900-1800-2100-2600 MHz

2G standards

Edge- GPRS- GSM

3G standards

DC-HSPA+-HSPA-HSPA+-UMTS

4G standard

LTE

Network

Guest access

Yes

Ethernet LAN interface type

Fast Ethernet

Ethernet LAN

Yes

VPN tunnels quantity

VPN support

PPTP- L2TP- IPSec

Receiver sensitivity

5GHz: 11a 54M: -74dBm11ac HT20: -67dBm11ac HT40: -64dBm11ac HT80 : -60dBm11n HT20: -71dBm11n HT40: -70dBm2.4G: 11g 54M: -76dBm11n HT20: -73dBm11n HT40: -67dBm

Port forwarding

Yes

Networking standards

IEEE 802.11a-IEEE 802.11ac-IEEE 802.11b-IEEE 802.11g-IEEE 802.11n

Ethernet LAN data rates

10-100 Mbit/s

Cabling technology

10/100Base-T(X)

VPN Passthrough

Yes

Dynamic DNS (DDNS)

Yes

Protocols

DMZ support

Yes

Supported network protocols

IPv4- IPv6

DHCP server

Yes

DHCP client

Yes

Security

VPN tunnels quantity

VPN support

PPTP- L2TP- IPSec

Security algorithms

64-bit WEP-128-bit WEP-WPA-WPA-PSK-WPA2-WPA2-PSK

Guest access

Yes

Firewall

Yes

DoS attack prevention

Yes

DMZ support

Yes

Stateful Packet Inspection (SPI)

Yes

Access Control List (ACL)

Yes

Performance

Windows operating systems supported

Windows 10-Windows 2000-Windows 7-Windows 8-Windows 8.1-Windows 98SE-Windows NT-Windows Vista-Windows XP Home-Windows XP Home x64-Windows XP Professional-Windows XP Professional x64

Mac operating systems supported

macOS

Linux operating systems supported

Yes

Memory card slot(s)

Weight & dimensions

Package width

307 mm

Package height

70 mm

Package depth

223 mm

Width

174 mm

Height

33.5 mm

Depth

124.5 mm

Certificates

Certification

CE- RoHS

Packaging content

Package type

Box

Cables included

LAN (RJ-45)

AC adapter included

Yes

Quick installation guide

Yes

WAN connection

Ethernet WAN

Yes

DSL WAN

SIM card slot

Yes

3G/4G USB modem compatibility

WAN connection type

RJ-45

Wireless LAN features

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

WLAN data transfer rate (max)

867 Mbit/s

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

WLAN data transfer rate (first band)

450 Mbit/s

WLAN data transfer rate (second band)

867 Mbit/s

Wi-Fi standards

802.11a-Wi-Fi 5 (802.11ac)-802.11b-802.11g-Wi-Fi 4 (802.11n)

Ports & interfaces

USB port

Ethernet LAN (RJ-45) ports

DC-in jack

Yes

Memory card slot(s)

Management features

WPS push button

Yes

Web-based management

Yes

Reset button

Yes

Quality of Service (QoS) support

Yes

Design

Product type

Tabletop router

Wall mountable

Yes

On/off switch

Yes

LED indicators

LAN- Power- Status- WLAN

Product colour

Black

Software

Windows operating systems supported

Windows 10-Windows 2000-Windows 7-Windows 8-Windows 8.1-Windows 98SE-Windows NT-Windows Vista-Windows XP Home-Windows XP Home x64-Windows XP Professional-Windows XP Professional x64

Mac operating systems supported

macOS

Linux operating systems supported

Yes

Mac compatibility

Yes

Antenna

Detachable antenna(s)

Yes

Antennas quantity

Antenna type

Internal & external

Transmit power

CE:

Features

Certification

CE- RoHS

Power

Power source type

Output voltage

12 V

Output current

1.5 A

Operational conditions

Storage temperature (T-T)

-40 - 70 Â°C

Storage relative humidity (H-H)

5 - 90%

Operating temperature (T-T)

0 - 40 Â°C

Operating relative humidity (H-H)

10 - 90%

System requirements

Windows operating systems supported

Windows 10-Windows 2000-Windows 7-Windows 8-Windows 8.1-Windows 98SE-Windows NT-Windows Vista-Windows XP Home-Windows XP Home x64-Windows XP Professional-Windows XP Professional x64

Mac operating systems supported

macOS

Linux operating systems supported

Yes

Mac compatibility

Yes

Packaging data

Package width

307 mm

Package type

Box

Package height
